Configure Windows Authentication Login

Follow the instructions below for setting up your Windows Authentication Login.

SCS-VR Setup Console and the SCS-VR Service run as different users by default. To use Windows Authentication, the database administrator will need to set up logins with appropriate authority on the VR databases.

  • If the service and database are on the same machine, the service login will look something like:
    NT AUTHORITY\SYSTEM.

  • If the service and database are not on the same machine, the service login will look something like: <domainname>\<machinename>\$.

Launch the Service

  1. Open the Database Configurator.

  2. Turn on Use Windows Auth.

  3. Select Test Connection.

Setup Console

In the Setup Console, leave the Username and Password field blank.

User Login Management

Specific User

To set up the service to run for a specific user login, follow the steps below.

Note: If the user's password changes, the admin will need to change the password on this service configuration.

  1. In Services, select SCS-VR.

  2. Go to the Log On tab.

  3. Select This account and enter the account and password.

  4. Select Apply.

  5. Select OK.

Default User

To set up the service to run with the default computer login, set up the logins in SQL SERVER.

Login Permissions

When the VR and database are on the same machine, the default user will be: NT AUTHORITY \SYSTEM.

  1. Double-click the service.

  2. Go to User Mapping.

  3. Select the Users mapped to this login.

  4. Select the user permissions under Database role membership.

  5. Select OK.

When the VR and database are on separate machines, the service user will look something like:
<domainname>\<machinename>\$.

  1. Double-click the service.

  2. Go to User Mapping.

  3. Select the Users mapped to this login.

  4. Select OK.
